LDX-3210-885

Laser Diode by RPMC Lasers Inc.
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to RPMC Lasers Inc..

The LDX-3210-885 from RPMC Lasers Inc. is a Laser Diode with Wavelength 885 nm, Output Power 2000 mW (Fiber) to 2500 mW, Output Power 2000 to 2500 mW, Threshold Current 200 mA, Operating Current 2500 mA. More details for LDX-3210-885 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    LDX-3210-885
  • Manufacturer
    RPMC Lasers Inc.
  • Description
    885 nm Multimode Laser Diode

General Parameters

  • Type
    Free Space Laser Diode, Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    885 nm
  • Output Power
    2000 mW (Fiber) to 2500 mW
  • Output Power
    2000 to 2500 mW
  • Spectral Width (FWHM)
    2.4 nm
  • Configuration
    Single-Emitter
  • Beam Divergence
    7 Degrees (Parallel), 44 Degrees (Perpendicular)
  • Beam Divergence Parallel
    7 Degrees
  • Beam Divergence Perpendicular
    44 Degrees
  • Wavelength Tolerance
    10 nm
  • Transverse Mode
    TE
  • Threshold Current :
    200 mA
  • Operating Current
    2500 mA
  • Operating Current
    2500 mA
  • Operating Voltage
    2 V
  • Laser Color
    Infrared
  • Emitting Size/Emitter Chip
    100 µm
  • Fiber Modes
    Multi-Mode
  • Package Type
    C-Mount, B-Mount, Q-Mount, Chip, Sub-Mount, TO-Can, HHL, HHL Pigtail
  • Package
    Cstd, B, Q, COS, TO3 w/o TEC, HHL, BFC w/o TEC, FCP

Physical Properties

  • Fiber length
    100 µm (HHL, Butterfly), 250 µm (9mm SMA)

Temperature

  • Operating Temperature
    25 Degree C
